XO-1 AWD SUPERCAR NO BATT TSM

  • Sale
  • Regular price $ 799.99


XO-1 (#64077-3) SPECS
Length: ­ 27 inches (686 mm)
Front Track: ­ 11.61 inches (295 mm)
Rear Track: ­ 11.81 inches (300 mm)
Center Ground Clearance: ­ 0.59 inches (15 mm)
Weight: ­ 137.6 ounces (3.9 kg) (w/o batteries)
Height (overall): ­ 5 inches (127.5 mm)
Wheelbase: ­ 15.9 inches (404 mm)
Front Shock Length: ­ 83 mm
Rear Shock Length: ­ 86 mm
Front Tires (pre-glued): ­ Belted slick (4.29" x 1.7")
Rear Tires (pre-glued): ­ Belted slick (4.29" x 2")
Front Wheels: ­ 3.3" Split-Spoke™ (black-chrome)
with 17 mm splined hex
Rear Wheels: ­ 3.3" Split-Spoke™ (black-chrome)
with 17 mm splined hex
Speed Control Type: ­ Castle Mamba Monster Extreme
forward/reverse/brake
Motor (electric): ­ Traxxas Big Block Brushless (1650 kV)
Transmission: ­ Single-speed
Overall Drive Ratio: ­ 9.36 (stock, out-of-box)
Differential Type: ­ Sealed hardened steel bevel
Gear Pitch: ­ Module 1.0
Chassis Structure/Material: ­ 3mm plate, dual plane, 6061-T6 aluminum
Brake Type: ­ Electronic
Drive System: ­ Shaft-driven 4WD
Steering: ­ Bellcrank
Transmitter: ­ TQi™ 2.4GHz Radio System with Traxxas Link Wireless Module
Receiver: ­ TSM® Receiver (#6533)
Top Speed: ­ 100+mph
Skill Level: ­ 10
Battery Tray Dimensions: ­ 155mm x 50mm x 29mm (adjustable height and length)
Required Batteries & Charger:

Two Traxxas Power Cell LiPo batteries (LiPo, 3-Cell 5,000 mAh), 4 "AA" (transmitter), LiPo battery charger



CASTLE CREATIONS MAMBA MONSTER EXTREME ESC SPECS
Input voltage (cells): ­ 18 NiMH 6s LiPo (max: 25.2 volts)
Case Size: ­ 2.2" x 1.9" x 1.4"
Weight: ­ 4.27 ounces (121 grams)
On-Resistance­ (@Trans)–FWD/REV: ­ 0.0003 ohms per phase
Reverse Delay: ­ Yes, with lockout
Low Voltage Detection (LVD): ­ Yes, programmable
