SEHREEFS159 RC RAW 500 Brass Edition Servo Programable
SEHREEFS159 RC RAW 500 Brass Edition Servo Programable is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
FULLY PROGRAMMABLE High Torque High Speed Brushless Servo SUBMARINE WATERPROOF: 7 Point Seals Magnetic Angle Sensor Pulse Width Modulation Control Fully Programmable w/ REEFS Software REEFS LINK required for Programming Voltage 4.8V - 8.4V / Bearing Type: 2 Ball Bearings Internal: Steel Gears / Brass Casing, Ultra Finish Weight: 5.2oz / 145.2G Dimension: 1.57 x .79 x 1.5 (LWH) Torque: 450oz @ 6v/ 500oz @7.4v/ 565oz @8.4v Speed: .11sec @6v/.095sec @7.4v/.08sec @8.4v Spline: 25T / Dead Band Width: 2¦Ìs BEC Not Req. Recommended for max performance. Unload Current: 320mA @ 6.0V / 360mA @ 7.4V / 400mA @ 8.4V Loading Current: 4000mA @ 6.0V / 4300mA @ 7.4V / 4600mA @ 8.4V
- Full Programmable
- High Torque High Speed Brushless Servo
- Submarine Waterproof: 7 Point Seals
- Magnetic Angle Sensor
- Pulse Width Modulation Control
SEHREEFS159 RC RAW 500 Brass Edition Servo Programable Product Specs
- Bearing2 Ball Bearings
- Bushing Or BearingBearing
- Deadband2µs
- Gear TypeMetal
- Manufacturer #REEFS159
- Maximum Servo Speed.11sec @6v/.095sec @7.4v/.08sec @8.4v
- Maximum Servo Torque565oz @8.4v
- Product Height1.5" (38 mm)
- Product Length1.57" (40 mm)
- Product Weight5.2oz (145.2g)
- Product Width0.79" (20 mm)
- Servo Operating Voltage4.8 - 8.4V (HV)
- Servo Size CategoryStandard
- Servo TypeDigital
- Spline Count25 - Tooth
- Torque450oz @ 6v/ 500oz @7.4v/ 565oz @8.4v
