Application | 20-35oz sport planes, 2M/DLG sailplanes, 200mm electric helis, 1M & scale sailboats |
Bushing Or Bearing | Bushing |
Current Draw Idle | 10 mA |
Current Draw Stall | 550mA |
Deadband | Width, 5 ?s |
Gear Type | Nylon |
Maximum Servo Speed | 0.100-0.149 sec |
Maximum Servo Torque | 20-39 oz-in |
Motor Type | Three pole cored |
Product Height | 0.95 in (24.1mm) |
Product Length | 1.12 in (28.6mm) |
Product Weight | 0.28 oz (8g) |
Product Width | 0.46 in (11.6mm) |
Programmable | No |
Servo Operating Voltage | 4.8 - 6.0V |
Servo Size Category | Sub-Micro |
Spline Count | 15 Teeth |
