D646WP Standard Digital High Torque Waterproof Metal Gear Servo - HRC36646
Maximum Servo Torque | 105oz/in @ 4.8V, 162oz/in @ 6.0V |
Product Weight | 2.15oz (61.0g) |
Spline Count | 24 - Tooth |
Water-Resistant | Yes |
Application | Sport Aircraft, Cars, Boats |
Programmable | Yes |
Servo Size Category | Standard |
Current Draw Idle | 30 mA |
Product Width | 0.83" (21 mm) |
Current Draw Stall | 2,200 mA |
Motor Type | Brushed |
Servo Operating Voltage | 6.0 - 7.4V (HV) |
Connector Type | Universal |
Maximum Servo Speed | 0.24 sec/60 deg @ 4.8V, 0.16 sec/60 deg @ 6.0V |
Product Length | 1.65" (42 mm) |
Deadband | 4µs |
Input Voltage | 6.0V ~ 7.4V |
Product Height | 1.57" (40 mm) |
Servo Type | Digital |
Bearing | Dual Ball Bearing |
Bushing Or Bearing | Bearing |
Gear Type | Metal |
Wire Gauge | 22 AWG |
