HRC35496S RCD Inc HS-5496MH Standard Digital HV Metal Gear Servo
HRC35496S RCD Inc HS-5496MH Standard Digital HV Metal Gear Servo is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Hitec believes in developing the highest quality servos in the market at an affordable price. That philosophy stands true with the economical HS-5496MH metal gear digital sport servo. Based on the popular HS-5485HB, the HS-5496MH is the perfect match for match for sport airplanes up to 25% scale as well as sport cars and trucks. With 7.4 volt, 2-cell LiPo battery capability, The HS-5496MH delivers the power you need at a price you can feel good about! Trust your hobby to Hitec.
- Speed: @4.8V .17sec/60' / @6.0V .15sec/60'
- Torque: @4.8V 89oz/in / @6.0V 104oz/in
HRC35496S RCD Inc HS-5496MH Standard Digital HV Metal Gear Servo Product Specs
- Application50-64oz sport & scale planes, 2M & up sailplanes, 1M sailboat, 1:10 scale power boat
- BearingTop Ball Bearing
- Bushing Or BearingBearing
- Connector TypeUniversal
- Current Draw Idle12 mA
- Current Draw Stall1,400 mA
- Deadband4µs
- Gear TypeMetal
- Input Voltage6.0V ~ 7.4V
- Maximum Servo Speed0.17 sec/60 deg @ 6.0V, 0.15 sec/60 deg @ 7.4V
- Maximum Servo Torque89oz/in @ 6.0V, 104oz/in @ 7.4V
- Motor TypeBrushed
- Product Height1.49" (38 mm)
- Product Length1.57" (40 mm)
- Product Weight1.84oz (52.0g)
- Product Width0.78" (20 mm)
- ProgrammableYes
- Servo Operating Voltage6.0 - 7.4V (HV)
- Servo Size CategoryStandard
- Servo TypeDigital
- Spline Count24 Teeth
- Water-ResistantNo
- Wire Gauge25 AWG
HRC35496S RCD Inc HS-5496MH Standard Digital HV Metal Gear Servo
