At Hitec, we believe in developing the highest quality servos in the market at an affordable price. That philosophy stands true with the economical HS-5496MH metal gear digital sport servo. Based on the popular HS-5485HB, the HS-5496MH is the perfect match for match for sport airplanes up to 25% scale as well as sport cars and trucks. With 7.4 volt, 2-cell LiPo battery capability, The HS-5496MH delivers the power you need at a price you can feel good about! Trust your hobby to Hitec
Features
- End Point Adjustments
- Direction
- Fail Safe
- Dead Band
- Speed (Slower)
- Data Save / Load
- Program Reset
Specifications:
-
Operating Voltage Range (Volts DC): 6.0V ~ 7.4V
-
Speed (Second @ 60°): 0.17 ~ 0.15
-
Maximum Torque Range oz. / in.: 89 ~ 104
-
Maximum Torque Range kg. / cm.: 6.4 ~ 7.5
-
Current Draw at Idle: 12 mA
-
No Load Operating Current Draw: 190 mA
-
Stall Current Draw: 1,400 mA
-
Dead Band Width: 4 µs
